Hangzhou Juntai Plastic Products Co.,Ltd
| Item Number | DD170 | DD215 | DD260 | DD350 |
|---|---|---|---|---|
| Size | 6 inch | 8 inch | 9 inch | 12 inch |
| MOC | EPDM/Silicon membrane | EPDM/Silicon membrane | EPDM/Silicon membrane | EPDM/Silicon membrane |
| ABS/PP carrier plate | ABS/PP carrier plate | ABS/PP carrier plate | ABS/PP carrier plate | |
| Connector | 3/4"NPT male thread | 3/4"NPT male thread | 3/4"NPT male thread | 3/4"NPT male thread |
| Bubble Size | 4-5mm | 1-2mm | 1-2mm | 1-2mm |
| Design Flow | 1-5m3/h | 1.5-2.5m3/h | 3-4m3/h | 6-6m3/h |
| Flow Range | 6-9m3/h | 1-6m3/h | 1-8m3/h | 1-12m3/h |
| Headloss | 2000-3000Pa | 2000-4500Pa | 2000-4300Pa | 2000-4200Pa |
| Servise Area | 0.5-0.8m2 | 0.2-0.64m2 | 0.25-1.0m2 | 0.4-1.5m2 |
| Service Life | >5year | >5year | >5year | >5year |
